带语音时间和问候语的挂钟

本教程展示了如何使用创建 基于 Python 的挂钟 pygame，使用 pyttsx3 和 Vosk 进行 文本转语音 和 语音转文本。该应用程序侦听“时间”一词，并根据当前时间响应当前时间和问候语。

语言	型号
英语	`vosk-model-small-en-us-0.15`
日语	`vosk-model-small-ja-0.22`
中文	`vosk-model-small-cn-0.22`
西班牙语	`vosk-model-small-es-0.42`
法语	`vosk-model-small-fr-0.22`
印地语	`vosk-model-small-hi-0.22`

pygame：GUI 和图形。
数学：时钟指针的三角学。
日期时间：时钟和问候语的当前时间。
numpy：生成人工滴答声。
pyttsx3：文本转语音引擎。
线程：在后台运行 TTS/STT。
声音设备和vosk：语音转文本识别。
json & os：解析 Vosk 输出并处理文件。

3.Pygame初始化


       pygame.init()
pygame.mixer.init(frequency=44100, size=-16, channels=2)
screen = pygame.display.set_mode((WIDTH, HEIGHT))
pygame.display.set_caption("PyShine Wall Clock")

初始化 Pygame 和 音频混合器 以进行声音播放。
设置屏幕尺寸和窗口标题。

4. 常数和颜色


       BLACK = (0, 0, 0)
WHITE = (255, 255, 255)
RED = (255, 0, 0)
GRAY = (150, 150, 150)
DARK_GRAY = (50, 50, 50)
BUTTON_COLOR = (0, 128, 255)
BUTTON_HOVER = (0, 180, 255)
BUTTON_ACTIVE = (0, 200, 0)
LIME = (0, 255, 0)

定义用于钟面、指针、按钮和文本的颜色。

5. 时钟参数及字体


       center_x, center_y = WIDTH // 2, HEIGHT // 2
clock_radius = 150
font = pygame.font.SysFont('Arial', 24, bold=True)
date_font = pygame.font.SysFont('Arial', 20)
button_font = pygame.font.SysFont('Arial', 20, bold=True)
time_str_font = pygame.font.SysFont('Arial', 28, bold=True)

center_x, center_y：时钟中心。 clock_radius：钟面的尺寸。

数字、日期、按钮文本和 TTS 文本显示的字体。

6. 滴答声


       def create_tick_sound():
    ...
    tick_sound = pygame.sndarray.make_sound(sound_array)
    tick_sound.set_volume(0.5)
    return tick_sound

使用 NumPy 生成 短 1500Hz 的点击。
无需外部音频文件。
用于播放每秒滴答声。

7. 收听按钮


       button_rect = pygame.Rect(WIDTH // 2 - 80, 80, 160, 50)
listening_active = False
def draw_button(mouse_pos):
    ...

在屏幕上绘制按钮。 Error 500 (Server Error)!!1500.That’s an error.There was an error. Please try again later.That’s all we know.
控制麦克风监听状态。

8. 文本输入和 TTS


       def speak_time():
    ...
    threading.Thread(target=tts_func, args=(spoken_time_str,), daemon=True).start()

根据当前时间确定问候语。
格式语音文本：例如，"Good afternoon\nIt's 03:25 PM now!"。
在后台线程中启动文本转语音。
更新打字动画变量。

9.Wax 语音转文本设置


       MODEL_PATH = "vosk-model-small-en-us-0.15"
vosk_model = Model(MODEL_PATH)
recognizer = KaldiRecognizer(vosk_model, 16000)

加载离线 Vosk 模型。
识别器将音频字节转换为文本。
确保离线语音识别。

STT 回调


       def stt_callback(indata, frames, time_data, status):
    ...
    if "time" in result_text.lower():
        speak_time()

处理来自麦克风的音频。
将其转换为文本。
触发器 speak_time()当检测到关键字“时间”时。

10. 时钟绘图函数

钟面


       def draw_clock_face():
    ...

绘制外圈、小时数字、分钟刻度。
区分小时刻度（较粗）和分钟刻度（较细）。

钟针


       def draw_clock_hands():
    ...

根据当前时间绘制时针、分针、秒针。
每秒播放滴答声。
绘制中心枢轴圆。

日期显示


       def draw_date_display(now):
    ...

显示当前日期和星期几。

打字动画


       def draw_spoken_time():
    ...

像打字一样逐渐显示问候语和时间。
光标闪烁。
4 秒后自动清除。

11. 主循环


       def main():
    ...

处理事件：
辞职
ESC键
鼠标点击收听按钮
更新：
钟面
手
日期
输入问候语
收听按钮
以 30 FPS 运行。
确保流畅的动画和交互。

12. 入口点


       if __name__ == "__main__":
    main()

直接执行脚本时启动主循环。

主要.py

完整的工作源代码在这里：




       # Tutorial and Source Code available: www.pyshine.com

import ctypes
try:
    ctypes.windll.user32.SetProcessDPIAware()
except:
    pass
import pygame
import math
import datetime
import sys
import numpy as np
import pyttsx3
import threading
import time

#  VOSK STT IMPORTS
import sounddevice as sd
from vosk import Model, KaldiRecognizer
import json
import os

# Initialize Pygame
pygame.init()
pygame.mixer.init(frequency=44100, size=-16, channels=2)

# Screen dimensions
WIDTH, HEIGHT = 400, 600
screen = pygame.display.set_mode((WIDTH, HEIGHT))
pygame.display.set_caption("PyShine Wall Clock")

# Colors
BLACK = (0, 0, 0)
WHITE = (255, 255, 255)
RED = (255, 0, 0)
GRAY = (150, 150, 150)
DARK_GRAY = (50, 50, 50)
BUTTON_COLOR = (0, 128, 255)
BUTTON_HOVER = (0, 180, 255)
BUTTON_ACTIVE = (0, 200, 0)
LIME = (0, 255, 0)

# Clock parameters
center_x, center_y = WIDTH // 2, HEIGHT // 2
clock_radius = 150

# Fonts
font = pygame.font.SysFont('Arial', 24, bold=True)
date_font = pygame.font.SysFont('Arial', 20)
button_font = pygame.font.SysFont('Arial', 20, bold=True)
time_str_font = pygame.font.SysFont('Arial', 28, bold=True)

# Tick sound
def create_tick_sound():
    sample_rate = 44100
    duration = 0.05
    n_samples = int(sample_rate * duration)
    t = np.linspace(0, duration, n_samples, False)
    envelope = np.exp(-50 * t)
    waveform = 0.5 * envelope * np.sign(np.sin(2 * np.pi * 1500 * t))
    waveform_int16 = np.int16(waveform * 3276)
    sound_array = np.column_stack([waveform_int16, waveform_int16])
    tick_sound = pygame.sndarray.make_sound(sound_array)
    tick_sound.set_volume(0.5)
    return tick_sound

tick = create_tick_sound()
last_second = -1

# Button
button_rect = pygame.Rect(WIDTH // 2 - 80,  80, 160, 50)
listening_active = False  # Button state
printed=False
def draw_button(mouse_pos):
    global printed
    if listening_active:
        color = BUTTON_ACTIVE
        text_str = "LISTENING..."
        if  printed==False:
            print('Start listening...')
            printed=True
    else:
        color = BUTTON_HOVER if button_rect.collidepoint(mouse_pos) else BUTTON_COLOR
        text_str = "LISTEN"
        printed=False
    pygame.draw.rect(screen, color, button_rect, border_radius=10)
    text = button_font.render(text_str, True, WHITE)
    text_rect = text.get_rect(center=button_rect.center)
    screen.blit(text, text_rect)

# Shared variables
spoken_time_str = ""
typed_text = ""
typing_start_time = 0
typing_speed = 8
cursor_visible = True
last_cursor_toggle = 0
text_display_complete_time = None

# Speak time and trigger typing
def speak_time():
    global spoken_time_str, typed_text, typing_start_time, text_display_complete_time
    now = datetime.datetime.now()
    hour, minute = now.hour, now.minute

    # Determine AM/PM
    am_pm = "AM" if hour < 12 else "PM"
    hour_display = hour % 12
    hour_display = 12 if hour_display == 0 else hour_display

    # Determine greeting based on hour
    if 5 <= hour < 12:
        greeting = "Good morning"
    elif 12 <= hour < 17:
        greeting = "Good afternoon"
    elif 17 <= hour < 21:
        greeting = "Good evening"
    else:
        greeting = "Good night"

    # Combine greeting and time as two lines
    spoken_time_str = f"{greeting}\nIt's {hour_display:02d}:{minute:02d} {am_pm} now!"

    typed_text = ""  # Reset typing
    typing_start_time = time.time()
    text_display_complete_time = None

    # Speak TTS
    def tts_func(text):
        tts_engine = pyttsx3.init()
        tts_engine.setProperty('rate', 150)
        tts_engine.say(text.replace("\n", ". "))  # Speak as single sentence
        tts_engine.runAndWait()

    threading.Thread(target=tts_func, args=(spoken_time_str,), daemon=True).start()

#  VOSK STT SETUP
MODEL_PATH = "vosk-model-small-en-us-0.15"
if not os.path.exists(MODEL_PATH):
    print(f"Missing model folder '{MODEL_PATH}'")
    sys.exit(1)

vosk_model = Model(MODEL_PATH)
recognizer = KaldiRecognizer(vosk_model, 16000)
sd_stream = None  # Global reference to microphone stream

def audio_to_bytes(indata):
    try:
        return bytes(indata)
    except:
        return indata.tobytes()

def stt_listen_loop():
    global sd_stream
    try:
        with sd.RawInputStream(
            samplerate=16000,
            blocksize=8000,
            dtype='int16',
            channels=1,
            callback=stt_callback
        ) as stream:
            sd_stream = stream
            while listening_active:
                time.sleep(0.1)
    except Exception as e:
        print("Microphone error:", e)

def stt_callback(indata, frames, time_data, status):
    if status:
        print("Audio status:", status)
    data = audio_to_bytes(indata)
    if recognizer.AcceptWaveform(data):
        result_text = json.loads(recognizer.Result()).get("text", "")
        if result_text.strip():  # Only print non-empty text
            print(f"Detected: {result_text}")
        if "time" in result_text.lower():
            speak_time()

# CLOCK DRAWING FUNCTIONS

def draw_clock_face():
    pygame.draw.circle(screen, WHITE, (center_x, center_y), clock_radius, 2)
    pygame.draw.circle(screen, DARK_GRAY, (center_x, center_y), clock_radius - 5, 2)
    for hour in range(1, 13):
        angle = math.radians(hour * 30 - 90)
        number_x = center_x + (clock_radius - 30) * math.cos(angle) - 10
        number_y = center_y + (clock_radius - 30) * math.sin(angle) - 10
        number_text = font.render(str(hour), True, WHITE)
        screen.blit(number_text, (number_x, number_y))
        tick_start_x = center_x + (clock_radius - 15) * math.cos(angle)
        tick_start_y = center_y + (clock_radius - 15) * math.sin(angle)
        tick_end_x = center_x + (clock_radius - 5) * math.cos(angle)
        tick_end_y = center_y + (clock_radius - 5) * math.sin(angle)
        pygame.draw.line(screen, WHITE, (tick_start_x, tick_start_y), (tick_end_x, tick_end_y), 3)
    for minute in range(60):
        if minute % 5 != 0:
            angle = math.radians(minute * 6 - 90)
            tick_start_x = center_x + (clock_radius - 10) * math.cos(angle)
            tick_start_y = center_y + (clock_radius - 10) * math.sin(angle)
            tick_end_x = center_x + (clock_radius - 5) * math.cos(angle)
            tick_end_y = center_y + (clock_radius - 5) * math.sin(angle)
            pygame.draw.line(screen, GRAY, (tick_start_x, tick_start_y), (tick_end_x, tick_end_y), 1)

def draw_clock_hands():
    global last_second
    now = datetime.datetime.now()
    hour, minute, second = now.hour % 12, now.minute, now.second
    if second != last_second:
        tick.play()
        last_second = second
    hour_angle = math.radians(hour * 30 + minute * 0.5 - 90)
    minute_angle = math.radians(minute * 6 + second * 0.1 - 90)
    second_angle = math.radians(second * 6 - 90)
    hour_x = center_x + clock_radius * 0.5 * math.cos(hour_angle)
    hour_y = center_y + clock_radius * 0.5 * math.sin(hour_angle)
    pygame.draw.line(screen, WHITE, (center_x, center_y), (hour_x, hour_y), 6)
    minute_x = center_x + clock_radius * 0.7 * math.cos(minute_angle)
    minute_y = center_y + clock_radius * 0.7 * math.sin(minute_angle)
    pygame.draw.line(screen, WHITE, (center_x, center_y), (minute_x, minute_y), 4)
    second_x = center_x + clock_radius * 0.8 * math.cos(second_angle)
    second_y = center_y + clock_radius * 0.8 * math.sin(second_angle)
    pygame.draw.line(screen, RED, (center_x, center_y), (second_x, second_y), 2)
    pygame.draw.circle(screen, RED, (center_x, center_y), 8)
    pygame.draw.circle(screen, WHITE, (center_x, center_y), 8, 2)
    return now

def draw_date_display(now):
    date_text = date_font.render(now.strftime("%Y-%m-%d"), True, WHITE)
    day_text = date_font.render(now.strftime("%A").upper(), True, WHITE)
    date_rect = date_text.get_rect(midtop=(center_x, center_y - clock_radius + 70))
    day_rect = day_text.get_rect(midtop=date_rect.midbottom)
    screen.blit(date_text, date_rect)
    screen.blit(day_text, day_rect)

def draw_spoken_time():
    global typed_text, last_cursor_toggle, cursor_visible, text_display_complete_time, spoken_time_str
    if spoken_time_str:
        elapsed = time.time() - typing_start_time
        # Split into lines
        lines = spoken_time_str.split("\n")
        chars_to_show = min(int(elapsed * typing_speed), sum(len(line) for line in lines))

        # Determine how many chars to show per line
        display_lines = []
        chars_remaining = chars_to_show
        for line in lines:
            if chars_remaining > len(line):
                display_lines.append(line)
                chars_remaining -= len(line)
            else:
                display_lines.append(line[:chars_remaining])
                break

        # Clear after 4 seconds of full display
        if chars_to_show == sum(len(line) for line in lines) and text_display_complete_time is None:
            text_display_complete_time = time.time()
        if text_display_complete_time and (time.time() - text_display_complete_time > 4):
            spoken_time_str = ""
            typed_text = ""
            return

        # Cursor blink timer
        if time.time() - last_cursor_toggle > 0.5:
            cursor_visible = not cursor_visible
            last_cursor_toggle = time.time()

        # Render each line
        y_offset = HEIGHT - 130
        for i, line in enumerate(display_lines):
            text_surface = time_str_font.render(line, True, LIME)
            text_rect = text_surface.get_rect(center=(WIDTH // 2, y_offset + i*35))
            screen.blit(text_surface, text_rect)

        # Draw cursor at end of last line
        if cursor_visible and display_lines:
            last_line = display_lines[-1]
            text_surface = time_str_font.render(last_line, True, LIME)
            text_rect = text_surface.get_rect(center=(WIDTH // 2, y_offset + (len(display_lines)-1)*35))
            cursor_x = text_rect.right + 2
            cursor_y = text_rect.top + 4
            cursor_height = text_rect.height - 2
            pygame.draw.rect(screen, LIME, (cursor_x, cursor_y-4, 3, cursor_height))


# MAIN LOOP
def main():
    global listening_active
    clock = pygame.time.Clock()
    running = True
    stt_thread = None

    while running:
        mouse_pos = pygame.mouse.get_pos()
        for event in pygame.event.get():
            if event.type == pygame.QUIT:
                running = False
            elif event.type == pygame.KEYDOWN and event.key == pygame.K_ESCAPE:
                running = False
            elif event.type == pygame.MOUSEBUTTONDOWN and event.button == 1:
                if button_rect.collidepoint(event.pos):
                    listening_active = not listening_active
                    if listening_active:
                        # Start background STT listening
                        stt_thread = threading.Thread(target=stt_listen_loop, daemon=True)
                        stt_thread.start()
                    else:
                        # Stop listening
                        print("Stopping listening...")
                        sd_stream = None

        screen.fill(BLACK)
        draw_clock_face()
        now = draw_clock_hands()
        draw_date_display(now)
        draw_spoken_time()
        draw_button(mouse_pos)
        pygame.display.flip()
        clock.tick(30)

    pygame.quit()
    sys.exit()

if __name__ == "__main__":
    main()






网站： https://www.pyshine.com 作者： PyShine

听和说的时钟

带语音时间和问候语的挂钟

目录

介绍

特点概述

模拟挂钟

内置滴答声

语音检测（STT）

文本转语音 (TTS)

打字动画

收听按钮

先决条件

安装依赖项

视窗

macOS

下载与上面相同的英文模型。

Linux

了解语音转文本 (Vosk)

为什么语音转文本很重要

免提交互

无障碍

实时自动化

无需屏幕即可工作

离线安全

Vosk 的工作原理——理论（简化）

MFCC 代表：

为什么开发人员喜欢 Vosk

蜡模型类型

小型号

中型型号

大型机型

从哪里获取语言模型

支持的语言

初学者应该使用哪种模型？

了解文本转语音 (pyttsx3)

改变声音

改变说话速度

代码分解

时钟渲染

滴答声生成

打字动画

监听按钮行为

STT回调逻辑

运行应用程序

故障排除

❗ 未检测到麦克风

❗ 未检测到语音

❗ TTS 只能运行一次

完整源代码

1.Windows DPI 感知

2. 进口

3.Pygame初始化

4. 常数和颜色

5. 时钟参数及字体

6. 滴答声

7. 收听按钮

8. 文本输入和 TTS

9.Wax 语音转文本设置

STT 回调

10. 时钟绘图函数

钟面

钟针

日期显示

打字动画

11. 主循环

12. 入口点

主要.py
